Information Library for Olympus Zuiko Lenses
Perspective Control Lense - Zuiko SHIFT 24mm f/3.5 - Operation


HTML Page (36k) Loading ...

Some notes on operations:
Switching of the built-in filter system
1) After switching the built-in filter, be sure to refocus the lense.
Setting the correct exposure
1) The viewfinder will show correct exposure ONLY when the lense is NOT shifted. If the lense is shifted, the indication MAY bary, but on AUTO mode, correct exposure will be formed.



Lense handling

1) the front lense element is made of special soft optical glass. During handling, extra care is needed to avoid scratches on it. If you are NOT taking pcitures, be sure to put the protective front lense cap on.
