Specifications |
Picture format: 24 x
36mm (standard 35mm film format)
Lens mount: Nikon F mount (with AF coupling, AF contacts) Lens D-type AF Nikkor
(except IX-Nikkor): Autofocus and all functions possible; PC Micro-Nikkor 85mm f/2.8D:
Usable in Manual exposure mode; AF Nikkor other than D-type (except AF Nikkor for
F3AF):
All functions except 3D Matrix Metering possible; AI-P Nikkor: All functions except
3D Matrix Metering and autofocus possible; IX-Nikkor: Cannot be used; Non-CPU: Usable
in Manual exposure mode (exposure meter cannot be used); Electronic Rangefinder usable
with lens with maximum aperture of f/5.6 or faster
Viewfinder : Fixed eye-level pentaprism, built-in deportee adjustment (-1.5
to +0.8 DP) Eye point 17mm (at -1.0 DP)
Focusing screen: B-type Clear Matte Screen
V with 5 focus brackets
Viewfinder frame coverage: Approx. 89%
Finder magnification (with illuminator)
: Approx. 0.68-0.60°- with 50mm lens set to infinity (at -1.5 to +0.8m-1)
Viewfinder information: Focus indications,
focus area, shutter speed, aperture, electronic analog exposure display/Exposure
Compensation value display, Exposure Compensation, flash ready-iight/ flash recommended/full
flash output, film status, battery power. Five sets of focus brackets (area), 12mmø
reference circle for Center-Weighted metering
Reflex mirror: Instant-return type, with
depth-of-field preview button
Depth of Field Preview: Possible.
Autofocus/Lens aperture: TTL phase detection,
Nikon Multi-CAM 900 autofocus module with AF-Assist Illuminator (approx. 0.5m-3m);
Detection range: EV -1 to EV 19 (ISO 100, at normal temperature)
Lens servo:- AF: AF: Auto-Servo AF: camera automatically chooses Single
Servo AF or Continuous Servo AF operation according to the subject status, i.e. stationary
or moving. M: Manual focus
Focus Area mode:- One of 5 focus areas
can be selected Dynamic AF Mode with Closest-Subject Priority; Dynamic AF Mode; Single
Area Mode with M (manual focus)
Metering system: TTL full-aperture exposure metering system; 3D 25-segment Matrix
Metering with G- or D-type AF Nikkor; 25-segment Matrix Metering with AF Nikkor other
than G or D-type (except AF Nikkor for F3AF and IX-Nikkor), AI-P Nikkor; Center-Weighted
Metering automatically selected with Manual exposure mode; Spot Metering
selectable in Auto Exposure lock with Custom Setting option (metering system in the
Auto Exposure lock)
Metering range: 3D 25-segment Matrix Metering:
EV 1-20, Center-Weighted Metering: EV 1-20, Spot Metering: EV 4-20 (at normal temperature,
ISO 100, f/1.4 lens)
Exposure meter: coupling CPU
Exposure compensation: Exposure compensated
in ±3 EV range, in 1/2 steps (except in M,
)
Auto Exposure Bracketing : Bracketing
range: ±2 EV; number of shots: three; bracketing steps: 0.5, 1, 1.5 or 2 EV
(except in or Vari-Program)
Film speed setting/Film speed range: •
Automatically set to ISO film speed of DX-coded film in use (manual not selectable);
Film speed range: DX: ISO 25-5000, automatically set to ISO 100 with non-DX-coded
film
Shutter:- Electronically controlled vertical-travel focal-plane shutter
Shutter speeds:• In ,
,
,
,
,
, P, A: Automatically
set between 30 and 1/2000 sec.
• In S: 30 to 1/2000 sec. (in 1/2 steps)
• In M: 30 to 1/2000 sec. (in 1/2 steps), Time
Sync contact: X-contact only; flash synchronization
up to 1/90 sec.
Built-in Speedlight: In , Vari-Program (except
in or ,) Automatically activated. In P, S, A,
M: activated by pressing flash lock-release button. Guide number:
12/39 (at ISO 100, m/ft); flash coverage: 28mm or longer lens; film speed range:
ISO 25 to ISO 800
 |
 |
Flash control : Front-Curtain Sync (normal sync), Slow Sync, Rear-Curtain Sync, Red-Eye Reduction, Red-Eye Reduction with Slow Sync, Flash Cancel Controlled by TTL Sensor; Automatic Balanced Fill-Flash with TTL Multi Sensor: 3D Multi-Sensor Balanced Fill-Flash compatible with built-in Speedlight or optional Speedlight and D- or G-type Nikkor lens, Multi-Sensor Balanced Fill-Flash compatible with built-in Speedlight or optional Speedlight and CPU Nikkor lens other than D/G-type (except in Manual exposure mode); Standard TTL: in Manual exposure mode; Film speed range in TTL auto flash: ISO 25 to 800
Standard TTL: With built-in Speedlight, SB-28, 27, 26, 25, 24, 23, 22s, 22, 20 (See various Nikon AF Speedlights Models) and non-CPU Nikkor lens; or with built-in . Speedlight, SB-29, 28, 27, 26, 25, 24, 23, 22s, 22, 20 and exposure mode set to manual or metering system to Spot Flash sync mode
Ready-light: Flash fully charged: ready-light lights; Full output warning: ready-light blinks
Flash recommended indication:- Blinks when the subject is dark or backlit and Speedlight is recommended in P, S, A and M
Accessory shoe: Standard ISO-type hot-shoe contact (sync contact, ready-iight contact, TTL auto flash contact, monitor contact, GND), safety lock provided
Self-timer: Electronically controlled; timer duration: 10 sec.
Depth-of-field preview button:- Stop-down lens aperture by pressing depth-of-field preview button; electronically controlled
Film loading:Automatic advance with built-in motor; :
Single-frame shooting,
Continuous shooting; Film advance speed: approx. 1.5 fps (fresh batteries)Film rewind: Automatic rewind with built-in motor; Mid-roll rewind available
LCD panel information Shutter speed, aperture, exposure compensation, exposure compensation value, auto exposure bracketing, multiple exposure, flash sync mode, focus area, battery power, frame counter, self-timer, remote control
Multiple exposure: Selectable in P, S, A, M
Date/time imprint function (N75QD/F75QD model only): Built-in clock: 24-hour type with timing accuracy within ±90 seconds a month; leap year adjustment until December 31, 2049; Usable film: ISO 32 to 3200 DX-coded film; Display mode: Year/Month/Day, Day/Hour/Minute, No Imprint, Month/Day/Year and Day/Month/Year
Camera back: Hinged back with film confirmation window; F75QD: Data imprint LCD panel/buttons
 |
|
||||
Power switch: Power ON and OFF position
Exposure meter: Auto meter shut-off 5 seconds after power turned on if no operations are performed; activated by lightly pressing shutter release button after power is turned on
 |
Battery power confirmation: In LCD panel and inside the viewfinder with exposure meter on |
|
Usable
number of 36-exposure film rolls |
At 20°C/68°F |
at -10°C/14°F |
|
Without flash |
Approx. 40 |
Approx. 23 |
|
With flash for half of all exposures |
Approx. 12 |
Approx. 7 |
| * For autofocus operation using an AF Zoom-Nikkor 28-80mm f/3.5-5.6D lens, covering the full range from infinity (oo) to the closest distance and back to infinity (OO) before each shot, with a shutter speed of 1/125 sec. or faster | ||
 |
Tripod socket: 1/4 (ISO 1222) |
