Modern Classic SLRs Series :
Nikon F2 Photomic w/DP-1 Prism
Instruction Manual - Part V

File Size: HTML Page (34k) Loading ...

The following are some basic tips for keeping your camera in top condition.

Storage: Keep the camera in an Eveready case or compartment case when not in use to protect it from dust. Avoid storing the camera in excessively hot, cold or damp places. Always attach a body cap when the camera body is stored separately. Do not leave film in the camera for a long period. Never leave the shutter or self-timer cocked if the camera is to be stored overnight or longer.

Camera Body: Brush the inside of the camera periodically using a soft brush. Do not exert pressure on the shutter curtain as this may damage it. Keep the mirror free from fingerprints and dust. If smudges or fingerprints persist, use lens tissue moistened slightly with alcohol.

<<< --Merdeka Square, Kuala Lumpur. Copyright © images collecton 2000. Arthur Teng ® Hosted by: Malaysian Internet Resources

Lens: Keep the lens surface free from fingerprints and dust as far as possible. Use lens tissue to remove dust, never use cloth or ordinary tissue. If smudges or fingerprints persist, use lens tissue moistened sparingly with alcohol. Remember: Even an approved lens cleaner can cause damage if it seeps into the lens mount.

Keep the camera away from water: Avoid excessive moisture. When using the camera near water, guard against splashes, especially saltwater spray.

Never oil any part of the camera: Lubrication should be left to an authorized serviceman. Prior to taking a holiday trip or being assigned an important photo job, test your camera by making a few trial exposures. Check the meter in the Photomic finder.

Remember, it takes at least two or three weeks for processing the test film and making any needed repairs or adjustment. Follow this important precaution and you will have pictures to remember.


Type: 35 mm single-lens reflex camera.
Lens mount: Nikon F bayonet mount.
Viewing system: F2 Photomic Finder with 100% frame coverage, exposure data visible in the viewfinder. Type A Focusing Screen supplied as standard equipment.
Titanium focal-plane shutter with speeds from 1 to 1/2000 sec., plus B. T and X synch.
Depth-of-field preview button:
Coaxial with mirror lock.
Mirror: Automatic instant-return type with Lock-up feature.

Self-timer: Can be set for 2-, 4-, 6-, 8- and 10-second delay.

Film-advance lever: Winds film, cocks shutter and operates frame counter with a single stroke or a series of strokes. Also switches meter on or off. Play angle of the lever is 20° and working angle 120°.
Frame counter:
Additive, automatic reacting.

Flash synchronization: At any speed except B. X and T with flashbulbs, and speeds up to 1/80 sec. with electronic flash.
Camera back: Hinged, detachable type.
Multiple exposure: Provided
Motor-drive linkup: Complete interchangeability.
F2 Photomic Finder:
TTL CdS meter featuring center-weighted metering at full aperture with Nikkor auto lenses; match needle indicate correct exposure, visible In the viewfinder and In the window on top of the prism housing; ASA range 6-6400; metering range EV-1~17 at ASA 100 (1 sec. at f/1.4-1/2000 sec. at f/8 with 50mm f/1.4 lens); aperture coupling range, f/1.2~ f/32; maximum aperture setting range, f/1.2~f/5.6; shutter-speed coupling range, 1~1/2000 sec., plus B. on direct coupling, and 10~2 sec. with manual override; powered by two 1.5V silver-oxide batteries.
Battery check
: Provided; Has a built-in ready-light for use with Nikon speedlights.
Weight: 220g for Photomic Finder Only.
