Modern Classic SLRs Series :
Nikon F2A Photomic w/DP-11 Finder
Instruction Manual -
Part IV

File Size: HTML Page (29k) Loading ...

Time Exposures

The Nikon F2A Photomic offers time exposure shooting convenience via built-in controls which enable long exposures without the need for accessory equipment. To make an exposure longer than 10 seconds, set the shutter-speed selector to "B" and turn the T-L finger guard to "T" as described in "Extra-long Exposures." Advance the film and press the shutter-release button to open the shutter. As long as the finger guard remains set to "T, the shutter will remain open. When returning the finger guard to the normal center position to close the shutter, be careful not to move or shake the camera, as a blurred image may result.

slowspeed.jpg turnknob.jpg
Note: Operation with a Nikon cable release can also provide for time exposures via the release's built-in locking function. For operation in these cases, leave the T-L finger guard in the center position and trigger the camera with the shutter speed dial set to the "B" setting.

High-Contrast Lighting Situations

When there are substantial brightness differences between the main subject and the background, unimportant bright spots or dark spots can adversely influence the finder reading, and thus the final exposure. To prevent under- or overexposure of the main subject under these shooting conditions, some corrective action must be taken to ensure proper exposure of the main subject. Fortunately, the finder's center-weighted TTL metering action simplifies adjustments, making for quicker camera operation and more accurate final results.

Metering with a bright area in the center will cause underexposure of the main subject. For correct exposure, first measure the main subject; then, recompose and shoot.

To compensate for an excessively bright or dark background, target the main subject in the center of the focusing screen while performing metering, this action ensures that the main emphasis of the meter reading will be on the chosen subject. Then, after completing aperture and shutter speed adjustments, recompose to the desired picture composition and make the exposure without readjusting the camera controls. For example, when shooting landscapes, it is often advisable to aim the camera slightly downward during exposure measurement to eliminate the effects of a bright expanse of sky; without such compensation, the landscape may appear underexposed in the final print. Also, for backlit subjects, it may be necessary to move closer to the subject to ensure a proper reading.


With some Nikkor lenses, full-aperture exposure measurement is not possible, either because the lens has no automatic diaphragm, or because the lens does not couple with the finder's meter- with certain accessories, too, lens/finder coupling is not possible, thus, preventing full aperture measurement. However, the camera's Photomic meter can still be used for exposure measurement via the stop-down method.

Before mounting the lens (or accessory) on the camera body, push the meter coupling lever up and to the right; with this action, the lever will remain locked up for stop-down exposure measurement (to release the lever after removing the lens/accessory, push the release to the right as described in "Coupling Lever Lock/Release Operation" section). Do a visual check each time to see if the meter couples with the lens after performing such operation.

After setting the finder, mount the lens or lens/accessory combination on the camera, switch on the meter by moving the film-advance lever to the standoff position, and then set the controls for correct exposure as follows.

For automatic diaphragm lenses with no coupling ridge, set the camera to the desired shutter speed; then, depress the depth-of-field preview button to stop down the lens diaphragm and, while holding the button depressed, adjust the aperture ring until the meter needle indicates correct exposure. Be sure to release the depth-of-field button prior to making the exposure.

For fixed-aperture lenses, such as Reflex-Nikkor lenses, simply adjust the shutter-speed selector until the meter needle indicates correct exposure. For convenience, shutter speeds can be set at intermediate settings in the 1/80 sec. to 1/2000 sec. speed range for precise exposures. If the meter indicates continuous overexposure, use a neutral density filter or slower film. If continuous underexposure is indicated, supplementary lighting or a faster film is necessary. This technique is also suitable for photography using a telescope or microscope.

For bellows units, extension rings and preset lenses, set the camera to the desired shutter speed; then, stop down the lens manually until the meter needle indicates correct exposure.


Adjustments for Focusing Screens

Light transmission properties vary somewhat with focusing screen type, thus occasionally requiring exposure correction to compensate for the combined effects of the lens/screen combination in use. The numbers listed in various blocks of the table on the opposite page denote the amount of correction necessary in f/stops.

To adjust the camera's finder for the indicated f/stop correction, lift and turn the ASA film-speed index ring until the ASA value for the film in use is aligned with the appropriate mark engraved on the ring. In the example figure shown, ASA 100 is aligned with the -1/2 mark to provide the correction required when using the Type C screen with the Nikon F2A Photomic camera and the Fisheye-Nikkor 6mm f/2.8 lens, as indicated in the table. (When "0" is indicated in the table, no compensation is required.)
