Canon EOS Resources SLR Cameras -Additional information relating to EOS700

File size: 23K HTML Loading....

Specifications Type & Major Components Type: 35mm focal plane shutter SLR (Single-Lens Reflex) camera with autofocus, auto exposure, built-in flash, and winder. QD version was available in Japan as EOS700QD, EOS700 for US and other markets. Lens Mount: Canon EF Mount (electronic signal transfer system). Standard Lense: Canon EF35-80mm f/4~5.6 Power Zoom. Usable Lenses: Canon EF lenses.

Viewfinder: Fixed eye-level pentaprism. Gives 92% vertical and horizontal coverage of actual picture area and 0.8X magnification with 50mm lens at infinity.
Focusing Screen: New laser-matte screen with AF frame.
Shutter: Vertical-travel metal focal plane shutter; all speeds electronically controlled.
Shutter Speed: 1/2000-1/4 sec. and bulb in shutter-priority AE. 1/2000-2 see. in other modes. X-sync is 1/125 sec.
Mirror: Quick-return half-mirror

Autofocus AF Control System: TTL-SIR (Secondary Image Registration) phase detection. Two modes available: One-shot or auto changeover of One-shot/Servo. Set automatically according to the exposure modes. AF Working Range: EV 1-18 at ISO 100 AF Auxiliary Light: Built-in AF illuminator operates automatically when required. Canon Autofocus EF Lens Resources

Exposure Control
Light Metering: TTL full aperture 6-zone metering using SPC (Silicon Photocell). Partial metering used in dose-up mode of P.I.C. Center-weighted average metering used in Deep Focus mode of P.I.C.
Metering Range: EV 0-20 with VIA lens at ISO 100 or equivalent Exposure Modes:

1. Intelligent Program AE
2. Depth-of-Field AE
3. Programmed Image Control (8 settings)
4. Shutter-priority AE
5. TTL program flash AE (with built-in flash or Speedlite 160E)
6. A-TTL program flash AE (with Speedlite 430EZ and 300EZ)

Film Transport Film Speed Setting: ISO 25-3200; automatically set in 1-step increments according to DX code. No manual setting available. Non-D X-coded film set to ISO 25. Film Loading: Automatic pre-wind system. Film Wind: Automatic, single frame or continuous (1.2 frames per second) set automatically according to the exposure modes.

Built-in Flash
Guide Number: 39-ft/12-m at ISO 100
Recycling Time: Approx. 2 sec -
Flash Coverage Angle: Covers the held of view of 35mm lens. Flash Fixing: Automatic in backlit or low-ligbt conditions in AUTO or no firing in OFF mode.

Others
Self-Timer: Electronically controlled with a 10-sec. delay
Date Imprint (EOS 700QD only): Four formats available with automatic calendar and clock programmed up to 2019

Power Source
Battery: One, 6V lithium battery pack (2CR5) supplies power to body and built-in flash.
Shooting Capacity: (with 24-exp. film and EF 35-80mm Power Zoom lens) Normal (68°F/20°C): 65 rolls without flash 35 rolls with 50% flash use Low (14° F/ - 10°): 35 rolls without flash 20 rolls with 50% flash use

Dimensions:
Size: EOS 700: 5-7/8 " (W) x 4-1/16 " (H) X 2-3/4 " (D) (149.3 x 102.2 x 69.5mm)
EOS 700QD: 5-7/8 " (W) X 4-1/16 " (H) X 2-13/16 (D) (149.3 x 102.2 x x 71mm)
Weight: EOS 700: 1.4 lb. (645 g) with battery; EOS 700 QD: 1.4 lb. (655 g) with battery

Quartz Date Imprint Function The EOS 700QD can imprint the current date in four different formats or be turned off completely. You'll always have a record of every shot you take. Note: All data are based on Canon's Standard Test Method. Subject to change without notice.
