EXPLAIN THE ADVANCED FEATURES BEHIND THE EASY CONTROL A unique approach to camera design sets the EOS 630 apart from any other 35 mm AF SLR. Explain the benefits behind the following technological features. to prospects.

Super-High -Speed Central Processing Unit
Offers expanded memory and faster computing power for quick autofocus and advanced program features.
EF Lens Mount Eliminates mechanical couplings through an advanced system of fully electronic data transfer for fast and accurate control.
Lens-integral AF system Allows AF focus drive motors to be precisely adapted to the specifications of each lens.
Arc Form Drive (AFD) motor Provides high-torque power in compact form to drive the autofocus systems of most EF lenses.
Ultrasonic Motor (USM) Offers efficient, virtually noiseless autofocus operation for selected "L" series lenses.
Electro -Magnetic Diaphragm (EMD) Offers precise aperture control and one-touch depth-of-field preview.
BASIS sensor Amplifies light readings to allow autofocusing down to the light of single candle-EV1

| Previous | NEXT | CREATIVE IMAGE CONTROL THAT TAKES UP WHERE PROGRAM AE LEFT OFF
